P10 Outdoor Full Color Waterproof HD LED Die-Casting Aluminum Cabinet 3 Years Warranty

P10 Outdoor Full Color Waterproof HD LED Die-Casting Aluminum Cabinet 3 Years Warranty

P10 Outdoor Full Color Waterproof HD LED Die-Casting Aluminum Cabinet 3 Years Warranty
P10 Outdoor Full Color Waterproof HD LED Die-Casting Aluminum Cabinet 3 Years Warranty
P10 Outdoor Full Color Waterproof HD LED Die-Casting Aluminum Cabinet 3 Years Warranty
Λεπτομέρειες:
Place of Origin: China
Μάρκα: SCXK
Πιστοποίηση: CE,ROHS ,FCC,UL
Model Number: SCXK-P10
Πληρωμής & Αποστολής Όροι:
Minimum Order Quantity: 1sqm can be available
Τιμή: Διαπραγματεύσιμα
Packaging Details: the led display can be packaged with wooden box,paper box,flight case
Delivery Time: 5-8days
Payment Terms: L/C, T/T, Western Union
Επικοινωνία
Λεπτομερής Περιγραφή Προϊόντος
Refresh Rate: 2500HZ/S pixel density: 10000dots/sqm
cabinet size: 960mm x 960mm Display Color: 16.7million
control system: 3G ,U-DISK ,wifi Power Supply: Series connection
Control method: Synchronization & Asynchronization LED Standard: Real Pixel(1R1G1B)
Protection Level: IP65

Fixing usage outdoor P10 LED Billboards , 960x960mm iron and steel cainet 3 years warranty





product description:



With the support of advanced technology and professional team, we have introduced world-class standard LED displays with beautiful images, long-lasting stability, low power consumption, wide viewing angle and high protection level.... Fully automated production to control our high quality, best color . Consistency for better performance.



-Energy saving, low power consumption, long life up to 100,000 hours (about 10 years) .
-We guarantee that the products supplied are new, complete and unused.
-Unique exhaust fan design, good heat dissipation and waterproof.

From material - production - testing - packaging - shipment, Shichuangxinke full quality control



Specificities:

1.Automatic brightness control,super processing ability,strong colour restoration.


2.Support various interfaces and signal sources.


3.Advanced digital control technology, excellent effect.


4.High brightness,even in direct,full-on sunlight to ensure you attract more audience to get short ROI of your full color outdoor led display screen's investment.


5.Antiseptic and durable, can be used outdoor in all weather.
LED module has easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display system.


With full aluminum alloy structure for light weight and waterproof advantages, outdoor LED display is an perfect external multimedia LED display system designed for changeable and adverse outdoor environment.

P10 Outdoor Full Color Waterproof HD LED Die-Casting Aluminum Cabinet 3 Years Warranty 0



The outdoor P10 full color led display parameter as follows.

Product Name smd outdoor Full Color LED Display
Model No SCXK-P10
Physical Pixel Pitch 10mm
Pixel Type Real Pixel(1R1G1B)
Red LED Lamp Optotech
Green&Blue LED Lamp Hcsemitek
Module Size 320mmx160mm
Cabinet Size 960mmx960mm
Module numbers per cabinet 3pcsx6pcs=18pcs

Cabinet numbers 1pcsx1pcs=1pcs
Module Resolution 96x96
Pixel Density 15625dots/sqm
Drive IC MBI5124 and MBI5024
Best Viewing Distance 10m------200m
Drive Mode 1/4 scan



Wide application field :



Widely used in Advertising media,Concert, TV SHOW,Super mall, Entertainment,School,Government,Trading conversation,Commodity fair,Exhibition,Cinema,News conferences, Meeting room,Airport,Hotel,Station Hall and other Public Places.



We still have some other style led display.The parameter as follows.



       the outdoor full color led display module ( smd and dip are available)
Number Drive mode Moduel size Resolution Led standard pixel density
P4 1/8 scan 256x128mm 64x32 3in1 62500
p4.81 1/13scan 250x250mm 52x52 3in1 43222
p5 1/8 scan 160x160mm 32x32 3in1 40000
P6 1/8 scan 192x192mm 32x32 3in1 27778
P8 1/4scan 256x128mm 32x16 3in1 15625
P10 1/4scan 160x160mm 16x16 3in1 10000
P12 1/4scan 192x192mm 16x16 3in1 6944
P16 static scan 256x256mm 16x16 3in1 3906
P20 static scan 320x160mm 16x8 3in1 2500
P25 static scan 200x200mm 8x8 3in1 1600
P31.25 static scan 250x250mm 8x8 3in1 1024

                the indoor full color led display module( indoor usage only)
Number drive mode module size resolution led standard pixel density
p1.923 1/32scan 246x246mm 128x128 3 in 1 270420
p2 1/32scan 128x64mm 64x32 3 in 1 250000
p2.5 1/16scan 160x160mm 64x64 3 in 1 160000
p3 1/16scan 192x192mm 64x64 3 in 1 111111
p3.91 1/16scan 250x250mm 64x64 3 in 1 65410
p4 1/16scan 256x128mm 64x32 3 in 1 62500
p5 1/16/scan 320x160mm 64x32 3 in 1 40000
p6 1/16scan 384x192mm 64x32 3 in 1 27778
p7.62 1/8 scan 244x244mm 32x16 3 in 1 17222
p10 1/8 scan 320x160mm 32x16 3in 1 10000



P10 Outdoor Full Color Waterproof HD LED Die-Casting Aluminum Cabinet 3 Years Warranty 1

Q: What are the differences between the outdoor ,indoor, semi-outdoor LED display ?
A1:
Brightness: Indoor LED displays are much less bright than outdoor and semi-outdoor LED displays. Outdoor LED displays and semi-outdoor LED displays are close in brightness.
A2: Waterproof level: indoor and semi-outdoor LED display are not waterproof.

Q: What is the DIP? What is the SMD?
A1: DIP is a package technology which make the LED get through the PCB and then use the tin welding .
A2: SMD is a package technology which weld the LED on the surface of PCB .

Q: What is the difference between the SMD and the DIP?
A1: Brightness: The DIP modules are brighter than the SMD
A2:
Viewing Angle: SMD modules have a larger viewing angle than DIPs.
      Pixel Density: The pixel density of SMD is much higher than that of DIP.

Q: What is a pixel and pixel pitch?
A: The pixel is the smallest unit of light-emitting, consists of red, green and blue colors. The same as ordinary computer monitors.Pixel pitch refers to the center of the distance between two adjacent pixels.

Q. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

P10 Outdoor Full Color Waterproof HD LED Die-Casting Aluminum Cabinet 3 Years Warranty 2
